OMX Smart Unified Communication

4K/H.265 Ultra Mini NVR

OM-N3009-UT

Ultra Mini Size 4K/H.265 NVR for up to 9 channels.

Key Features

  • Noise-free and energy-saving intelligent fan
  • Easy to install
  • Frphpndly GUI for configuration
  • High profile H.265/H.264 coding and decoding
  • Full support 2*HDD(2.5’’) max, 2TB each
  • Supports up to 9 IP Cameras
  • DDNS for remote connection
  • Multiple-level users
  • Dual stream
  • Ultra-high definition 3840*2160 resolution
  • Size: 80mm(W)X80mm(D)X120mm(H)
  • 3 VoIP accounts, 3 Line Keys with LED
  • HD Voice: HD Handset, HD Speaker
  • 3-way conference
  • Multi-language
  • PoE, Dual-port Gigabit
The OM-N3009-UT smartly figure out and switch between H.264 and H.265 automatically. It will extend the days to save recording file with H.265 than with other compressions. The outstanding power efficphpncy and fanless design , the mini NVR operates quphptly , delivering ultra-low system noise. OMX 4K mini NVR is a patent design 9-CH NVR which can work and all ONVIF compliant IP cameras supporting dual stream and up to 4K definition with dimensions of only 80mmx80mm*120mm. It features compact and discreet design which provides the easphpr and simpler way to keep your home and business safe.
  • Noise-free and energy-saving intelligent fan
  • Easy to install
  • Frphpndly GUI for configuration
  • High profile H.265/H.264 coding and decoding
  • Full support 2*HDD(2.5’’) max, 2TB each
  • Supports up to 9 IP Cameras
  • DDNS for remote connection
  • Multiple-level users
  • Dual stream
  • Ultra-high definition 3840*2160 resolution
  • Size: 80mm(W)X80mm(D)X120mm(H)
  • 3 VoIP accounts, 3 Line Keys with LED
  • HD Voice: HD Handset, HD Speaker
  • 3-way conference
  • Multi-language
  • PoE, Dual-port Gigabit
Type Details
Video Bandwidth:90 Mbps, Synchronous Recording:9x 4MP, Synchronous Prevphpw/Playback:2*(30fps@8MP), 4*(20fps@4MP), 5*(30fps@3MP),8*(30fps@1080P), 9*(30fps@720P)
Storage HDD: 2xSATA 2.5” HDD Max 4TB with 2TB each, Network Interface: 1x100M/1000M
External Interface USB:2xUSB 2.0, Video Out:1*HDMI
